DF30AA160
DIOE MODULE 1600V 30AManufacturer: SanRex Corporation
Categories: Bridge Rectifiers
Quality Control: Learn More
SanRex Corporation DF30AA160 Three Phase Bridge Rectifier, part of the standard technology series, offers a robust solution for high-power AC to DC conversion. This chassis mount module features a peak reverse voltage rating of 1.6 kV and an average rectified forward current capacity of 30 A. It exhibits a maximum forward voltage of 1.3 V at its rated current and a reverse leakage current of 3 mA at 1600 V. The operating temperature range is specified from -40°C to 150°C (TJ). This component is commonly utilized in industrial power supplies, motor control, and renewable energy systems. The DF30AA160 is supplied in tray packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | Module |
| Mounting Type | Chassis Mount |
| Diode Type | Three Phase |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Technology | Standard |
| Supplier Device Package | - |
| Voltage - Peak Reverse (Max) | 1.6 kV |
| Current - Average Rectified (Io) | 30 A |
| Voltage - Forward (Vf) (Max) @ If | 1.3 V @ 30 A |
| Current - Reverse Leakage @ Vr | 3 mA @ 1600 V |
Request a Quote
